BPI-6202 embedded single-board industrial computer,use Allwinner A40I Industrial chip design, equipped with 2 independent MAC Ethernet ports (1G+100M), 2 RS485+1 RS232 ports, HDMI/USB, can be installed with large-capacity SDD hard disk, powerful and low price , Small size, easy guide rail installation, providing the most cost-effective on-site industrial control solution. As the master control node of edge computing, BPI-6202 makes full use of the powerful functions of embedded multi-core computing, which can access, process and display a large amount of on-site data; replace the conventional gateway + small monitoring system to achieve the optimal solution.
PCBA:
Product:
technical specifications:
| Processor/OS | Allwinner A40I ARM Cortex-A7 Quad Core 1.2GHz, Ubuntu/Mate |
|---|---|
| Memory | 2GB DDR3, 8GB EMMC; can be equipped with large-capacity SSD hard disk |
| Basic communication function | Ethernet port: 1 x 1000M + 1 x 100M, independent MAC, 2 x RS485 with isolation + 1 x RS232 Consoel with isolation, 4G/5G full Netcom + WiFi |
| Extended function module | Horizontal expansion capability is reserved, and the expansion of various functional modules can be customized. The initial stage includes: RS485: with isolation; DI: passive input type, the module provides 24V isolated power supply; DO: relay output type, NC, COM, NO nodes; AI: 0-5V/4-20mA, 2-wire/3-wire input, the board provides 24V isolated power supply; AO: 0-5V/4-20mA, 2-wire/3-wire output, external 24V isolated power supply; AI + AO: 0-5V/4-20mA, 2-wire/3-wire input/output. The power supply is the same as above; other custom modules |
| HMI interface | HDMI1.4, support 1080p@60fps ; USB supports keyboard, mouse; or resistive/capacitive display interface |
| Data processing capability | Equipment access capability: <=128 units (adjustable according to bandwidth and sampling period); analog value<10000; digital value<10000; control value<10000; expression calculation definition, alarm processing |
| video processing capability | Video RTSP/RTMP, Onvif, GB28181; video recording and playback; data trigger clip video recording and uploading; video AI event return and linkage, data OSD coding; local streaming service; H.264/H.265 playback |
| SCADA function | Full-featured SCADA system, processing points: 2048 points, C/S or B/S mode |
| development environment | Edge computing secondary development environment such as C/expression/ladder diagram/Java/Python |
| encryption chip | Software license authorization encryption chip (SMEC98SP); special encryption chip for State Grid communication (SC1161Y) |
| Power supply | DC：24V |
PCBA interface：
Product interface:
online wiki documents, keep update:
https://wiki.banana-pi.org/BPI-6202_Embedded_single_board_industrial_computer
