:wave: Welcome All …

This discussion is for sharing experiences with 5G and 4G :satellite: antennas. I’m using the BPI-R4 as a 5G router (Module m.2 Quectel RM551,RM520, Fibocom FM350), which has four antenna ports.

I’ve tried several types of antennas from AliExpress but haven’t had much luck finding one with genuinely good gain. Many sellers advertise high gain (around 12 dBi), but the actual gain is often closer to 4 dBi.

I’d appreciate any recommendations or links to reputable AliExpress stores that offer quality 5G/4G antennas with reliable gain (Like 8 DPI or 12 DPI or 15 DPI).

image1280×961 165 KB

Links : (These antennas their shops saying Gain 12 DPI but actual 4 or 5 DPI ) These antennas (600-6000mhz) tested on same Band , PCI and Location all not good

Third antenna starting from left

Bad Antenna with a lot of orders

======================================================================= Additional to above I ordered this type of antenna ( On-Way) Link : I will share my test for this antenna here Item


=================================================================

2

You don’t need any antennas, what you need is to place the Quectel modem on an 5G M.2 to RJ45 (RGMII) and then place it outside your home on an Outdoor PoE Antenna Enclosure and only use the BPI-R4 as a wireless router inside your house.

Outdoor PoE Antenna Enclosure

Source:

Videos:

3

Thank you Dear @Thanks … You are always adding a good efforts in each subject which is appreciated by all members…

Lets back to subject: Me and a huge number of people are looking for internal antennas to be fit on router like this (We are using BPI-R4 as 5G Router)

image-11-1024x728
image-11-1024x7281024×728 64.5 KB

Lets keep up to hear from others … Theirs experience …
