Banana Pi BPI-F3 with SpacemiT K1 8 core RISC-V chip,8G RAM and 16G eMMC

Banana PI RISC-V Design BPI-F3/BPI-CM6(SpacemiT K1)
1

Banana Pi BPI-F3 is a industrial grade RISC-V development board, it design with SpacemiT K1 8 core RISC-V chip, CPU integrates 2.0 TOPs AI computing power. 8G DDR and 16G eMMC onboard.2x GbE Ethernet prot, 4x USB 3.0 and PCIe for M.2 interface, supprt HDMI and Dual MIPI-CSI Camera.

Banana Pi BPI-F3 banner 5
Banana Pi BPI-F3 banner 5800×428 114 KB

Key Features

  • 8 core RISC-V chip, CPU integrates 2.0 TOPs AI computing power
  • Single-core general computing power equivalent to 1.3 times Cortex-A55
  • Supports 32-bit LPDDR4/4X, with a maximum of 16GB of memory
  • 4K decoding and encoding
  • 5-lane PCIE2.1 expansion capability
  • 1x USB 3.0 + 2x USB 2.0 interfaces
  • 12x UART serial ports
  • Operating temperature range: -40°C to 85°C

Hardware interfact:

Bananna Pi BPI-F3 interface
Bananna Pi BPI-F3 interface800×1005 245 KB

图片11159×574 253 KB

Online documents: Banana Pi BPI-F3 | BananaPi Docs

Banana Pi BPI-F3 RISC-V SBC product Introduction

#SBC #raspberrypi #bananapi #orangepi #riscv #iot #industry #automobile #AI

2 Likes
2
3

Banana Pi BPI-F3 SpacemiT K1 8 core RISC-V chip Brief

4

Banana Pi BPI-F3 SpacemiT K1 8 core RISC-V chip run OpenWRT, are you want to do a NAS??

5

Banana Pi BPI-F3 RISC-V SBC Linux Run GMIP Test

Banana Pi BPI-F3 RISC-V board test :At the same time, play 9 local 1080P movies

6

Banana Pi BPI-F3 RISC-V SBC Power consumption test

7

Banana Pi BPI-F3 8 Core RISC-V SBC deployments run visual AI+ large models simultaneously

Banana Pi BPI-F3 RISC-V SBC run Ubuntu Linux test 8 Core CPU performance and AI function

8

Banana Pi BPI-F3 Review : Octa Core RISC-V SBC Running Bianbu OS.

9

SpacemiT K1 8 core RISC-V chip (Banana Pi BPI-F3) RISC-V IME set Specification public on github

1 Like
11

@sinovoip hi, I see a lot of Bianbu firmware updates here Index of /image/k1/version/bianbu Could you tell me a little bit what’s new on V2.0? I’m curious because I don’s see any ‘what’s new’ in any firmware. Thanks! Index of /image/k1/version/bianbu/v2.0alpha1

12

Looking at Bianbu Linux: Bianbu Linux是由SpacemiT维护的开源项目，提供Spacemit Stone系列芯片的BSP，即SDK。 probably it is the best place, I guess the most interesting change is that they moved to linux-6.6: Linux 6.6 supports SpacemiT Key Stone K1 CPU (in development) but sadly it is yet again a collapsed single-commit :confused:

13

Hi,

For the Banana Pi BPI-F3, can you please clarify where the PCI lanes go?

On the lower side of the BPI-F3 is a 22x80mm M.2 slot. Does it get 1 or 2 PCIe v2 lanes (4gbit or 8gbit total bandwidth)?

On the upper side of the BPI-F3 is a MiniPCI slot. It gets 1 lane of PCIe v2 right?

And, the K1 SoC has total 2+2+1 = 5 PCIe data lanes. Where do the other last 2 or 3 lanes go?

Thanks!

14

It would be helpful if admin gives me the access to start new threads, so I can start threads for the USB power etc. questions for the BPI-F3.

15

Is the BPI-F3 sold also without a wifi module?

If you de-solder the WIFI module, the F3 will work fine right.

Is the WIFI connected via SDIO?

–

Until now there is not so much activity here at forum.banana-pi.org regarding the BPI-F3.

What other chat rooms, forums and web sites discuss it? Please share references.
